Total Capacity / Model Name
Capacity 1.9 Tr
Rating 3 Star   3 Star
Refrigerant R32 R32
MRP₹ 64530
Catalogue
Add to Cart Add to cart

Features

4 Way Swing

Anti Rust

DC Fan Motor

Eco Cool

Grooved Piping

LCD Remote Control

PM Filter

Wide & Long Airflow

Technical Specifications

Type (Cooling)
Indoor Unit
MS-AGZ24VF
Outdoor Unit
MU-AGZ24VF
Performance Parameters
Capacity (Tr) 1.9 Tr
Star Rating - As Per BEE 3 Star  bee rating
Power Supply 230 V / 50 Hz / Single Phase
Rated Capacity 6650 W
Rated Power Input 1714 W
ISEER 3.88
Rated Current  (Amps) 7.82
Indoor Air Flow (m3/h) (Turbo/Hi/Mi/Lo) 1400
Indoor Noise(Low/Mid/Hi/Turbo Speed) 46/48/ 49/52
Refrigerant R32
Dimensions & Weight
IDU Dimension Net Dimensions (W x D x H) mm 1100 x 250x330
Net  Weight kg 14
Outdoor unit Net Dim (W * D * H) mm 910 x 330 x 752
Net Weight kg 54
Connecting Pipe Liquid and Gas Side Dia mm 15.88 / 6.35
Maximum Length m 20
Maximum Elevation m 10
Ambient Operating Range   °C 48°
Installation Kit (Includes Copper Kit/Insulation/Wire)   Included
